Yaskawa Z1000U Matrix HVAC Drive low harmonic distortion and space saving

The Z1000U Matrix Drive incorporates matrix technology to directly convert input AC voltage to output AC voltage. The drive is ideally suited for HVAC applications providing extremely low harmonic distortion, energy savings and serviceability in a space-saving design. The Z1000U was recently made the 2016 Product of the Year Winner by Consulting-Specifying Engineer magazine!

Feature Highlights

  • Low input distortion across a wide load and speed range
  • IEEE-519 Compliant (<5% THD)
  • Eco-Mode to achieve near across-the-line THD
  • High Efficiency Design provides extra energy savings as compared to other low harmonic solutions
  • Near Unity True Power Factor at full load
  • 0.98 Displacement Power Factor throughout entire load and speed range
  • Integrated Input Fusing provides 100kA SCCR
  • Integrated C2 EMC Filter
  • Compact Design
  • High Reliability with an MTBF of 28 Years
  • Embedded BACnet communications (BTL Certified)
  • Embedded real time clock for event stamping
  • High Carrier Frequency (Low Motor Noise) Capability
  • 0-400 Hz Output Frequency
  • 120% Overload for 60 Seconds
  • Motor Auto-tuning
  • Multi-language LCD display, with Hand/Off/Auto and Copy function
  • DriveWizard® HVAC Software
  • Embedded Timer Functions for Starting, Stopping and Speed Changes
  • Start into spinning load (speed search)
  • Both Induction and Permanent Magnet Motor Control
Yaskawa-U1000-small-png

MATRIX Z1000U HVAC Drive

  • Full regeneration
  • Low input distortion across a wide load and speed range

MATRIX Z1000U Features & Benefits
